Factory Price Hdpe Cosmetics Plastic Bottles Making Injection Blow Molding Machine

Availability:
Quantity:
Product Intruduction
Three station - one step injection blow molding machine, suitable for processing PP, PS, PE, SAN, PMMA, PC, PETG, PEN...plastic material,product volume from 3-1000ml, widely used in pharmaceutical, health care products, food and beverage, cosmetics, etc..One Mold with Multi-caivity for automatic continuous production technology, using three horizontal station rotary device, hot runner system and multi-stage injection molding system,injection molding, blow molding, demolding three position and action to ensure equipment of high efficiency and energy saving operation, ensure smooth product bottle, the bottleneck of inner and outer diameter and thread high precision, no waste is the standard equipment of modern enterprise environment-friendly production. Horizontal injection system,plasticing reliable and operation easy.Single crossbeam style clamping system,easy for mould amounting.Variable delivery pump driving system, energy saved and effcient high. Big mould dimension,output higher than same level machine.
Product Paramenters
item
value
Plastic Processed
PE, PP, HDPE, PVC, PETG
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
New Product 2020
Warranty of core components
2 years
Core Components
Motor
Condition
New
Application
bottle
Blow Moulding Type
Injection Blow Moulding
Place of Origin
China

Jiangsu
Brand Name
U TECH
Year
2020
Voltage
220/380V 50/60HZ 3PH
Dimension(L*W*H)
3000*1300*1700mm
Certification
iso ce
Hollow part volume
1ml-1000ml
High Pressure Valve Brand
SMC
Clamping Force (kN)
400
Rotary Cylinder Brand
AirTac
PLC Brand
MITSUBISHI
Power (kW)
20
Weight (KG)
3500
Automation
Automatic
Warranty
2 years

Field maintenance and repair service, Field installation, commissioning and training, Free spare parts, Video technical support,
Online support
Key Selling Points
Sustainable
After Warranty Service
Video technical support, Online support, Spare parts, Field maintenance and repair service
Applicable Industries
Food & Beverage Factory
Local Service Location
United States, Philippines, Pakistan, Thailand, Kenya
Showroom Location
United States, Philippines, Pakistan, Thailand, Chile
Number of cavity
4 Cavity
Warranty
2 years
Weight
3500kg
Dimension(L*W*H)
3000*1300*1700mm
Heating Zone
3+N
Dry cycle time
3.5s
Screw Diameter
40mm
Compressing pressure
0.7~1.2Mpa
Control
Control+touch Screen
Function
injection blow molding
