Automatic 8000BPH 10000BPH Plastic Pet Bottle Coconut Milk Orange mango Guava Pomegranate Fruit Juice Bottling Machine

Availability:
Quantity:
Inquire Add to Basket

Description

RCGF series juice filling line is used to produce PET bottled juice within the volume from 200ml to 2000ml.different models can satisfy various requirement of output from 1500B/H to 25000B/H.this machine incorporates ringsing,filling and capping into one kind of full-automatic equipment.It is suitable for producing PET and Plastic bottled juice and tea.The method of filling adopts hot filling .The equipment is fitted with advanced Mitshbishi PLC to control the operation and cooperated by frequency converter of the main motor.it makes the operation more stable and reliable.the photoelectric sensor is used to detect operating confitions of each section,which makes the operation of this equipment highly automatic and convenient.

Sample

Technical Parameters

Model

RCGF8-8-3

RCGF14-12-5

RCGF16-16-5

RCGF24-24-6

RCGF32-32-8

RCGF40-40-10

capacity(BPH)

1500

(500ML)

4000

（500ML）

5500

(500ML)

8000

(500ML)

10000

(500ML)

14000

(500ML)

washing heads

8

14

16

24

32

40

filling

heads

8

12

16

24

32

40

capping heads

3

5

5

6

8

10

suitable bottle

PET bottle plastic bottle

diameter of bottle

55-100mm

height of bottle

150-300mm

suitable cap

plastic screw cap

weight(kg)

1500

2000

3000

5000

7000

7800

main motor power(kw)

1.2

1.5

2.2

2.2

3

3.5
