Automatic Small Drinks Whisky Alcohol Glass Bottle Wine Filling Sealing Machine Line

Availability:
Quantity:

Introduction

Product IntroductionThis glass bottle filling machine adopts advanced SIEMENS programmable logic controller (PLC) to control the automatic running of the machine. The input bottle adopts air conveying device; the output bottle adopts adjustable speed way, which combines with the transducer of the host machine making the output bottle running more stable and reliable. The photoelectrical inspection of the running condition of various parts makes a higher automation and convenient operation. It is the ideal first-choice equipment of beverage manufacturers.

Technical Parameters

Model

Washing Filling Capping  Capacity(b/h)500ml Motor power Overall dimension(mm)
heads heads heads (KW)
BFGF14-12-5 14 12 5

2000bph

1.5KW

2100x1400x2500
BFGF18-18-6 18 18 5 3000bph 2.2KW 2460x1720x2650
BFGF24-24-6 24 24 6 4000bph 3KW 3100x2100x2650
BFGF32-32-10 32 32 10 6000bph 4KW 3500x2500x2650
BFGF40-40-10 40 40 10 8000bph 7.5KW 4600x1800x2650

Machine Details

细节空图

Features

1. Rinsing empty bottle, filling, and capping functions are integrated in one system, fully automatic synchronized working.Bottle travels on neck to neck from in-feed till out-feed resulting scratch free movement of bottle.
2. Pressure or vacuum filling nozzles deliver fast, efficient, and accurate dispensing with minimal dripping and leakage.

3. No Bottle No Filling, no caps no capping, no caps auto stops.When bottle jam auto stop, machine accident auto stop.Open the window when machine running, machine auto paused.Heavy duty stainless steel filling pump & rinsing pump.Food grade 316L or 304stainless steel contact parts, smooth & fine Polish, no dead angles.
