10L 20 Liters Plastic Jerry Can Extrusion Moulding Making Machine 25L Hdpe Bottle Jerrycan Blow Molding Machine

Availability:
Quantity:
Inquire Add to Basket

Products Description
Machine Details
Related Products
Technical Parameter
Model
Unit
BST-80
Max. Product Volume
(L)
30L
Dry cycle
(pc/h)
60
Screw Diameter
(mm)
80
Screw L/D ratio
(L/D)
25
Screw drive power
(KW)
37
Screw heating capacity
(KW)
18
No. of heating zone
(ZONE)
4~6
Max. Output of HDPE
(Kg/hr)
100-140
Oil pump drive power
(KW)
18.5(22)
Clamping force
(KN)
240
Platen distance
(mm)
270-820
Mold moving stroke
(mm)
390
Max. Size of Mold(W*H)
(mm)
600x750
Max. Die diameter
(mm)
250
Die heat capacity
(KW)
9.6
No. of heating zone
(ZONE)
4~6
Central distance of Double head
(mm)
/
MOOG Parison controller power
(KW)
4
Average Power Consumption
(KW)
40
Blowing pressure
(Mpa)
0.7
Air volume
(M3/MIN)
0.8
Cooling water pressure
(Mpa)
0.3~0.5
Water consumption
(L/MIN)
50
Size of machine ( L*W*H)
(m)
5.20*2.90*4.60
Weight of machine
(TON)
13.5
